Curtiss-Wright Controls Defense Solutions Debuts Complete Embedded Radar Acquisition and Scan Conversion System on a Single VME Card
New SoftScan/1905 Single-Slot 6U VME Subsystem Delivers Industry-Leading Radar Acquisition and Display Capability
(firmenpresse) - ASHBURN, VA -- (Marketwire) -- 03/23/12 -- (CWCDS) has announced the availability of , its new integrated embedded Radar Acquisition and Scan Conversion system that combines the company's unique and a rugged, high performance COTS 6U VME single board computer (SBC).
"SoftScan/1905 demonstrates Curtiss-Wright's unique ability to provide radar acquisition, processing and display as a complete embedded solution," said Lynn Bamford, senior vice president and general manager of Curtiss-Wright Controls Defense Solutions. "Our advanced software technology coupled with proven hardware address our customers' most demanding requirements, supporting both legacy and modern radar systems."
SoftScan/1905 hardware comprises a 6U VME CWCDS and an graphics controller mezzanine card. The system's display controller supports dual-head graphics output on DVI-I single-link (dual-head output) or dual-link (single-head output), with resolutions up to 1600x1200 (single link) or 2560x1600 / 2048x2048 (dual-link, single head).
The SoftScan software, which is supported on both PC-based systems for application development and embedded platforms for system deployment, uses advanced GPU-accelerated algorithms to deliver unmatched scan-conversion performance while off-loading the host processor. This enables the SBC's main processor to be primarily dedicated to the processing of the customer's computationally demanding application code. SoftScan radar scan conversion supports polar format radar data input either via its network interface from a CWCDS Radar Video Processor (RVP) server or via an optional on-board Osiris PMC radar acquisition card. Plan Position Indicator (PPI), A-scan and B-scan display formats are supported with rapid pan and zoom.
SoftScan's powerful proprietary algorithms eliminate holes or spokes in the displayed image at any range or zoom level. SoftScan also ensures that all single point targets are displayed. Multiple windows may be created, each displaying multiple radar sources, and all windows are movable and resizable in real time.
SoftScan is implemented as a set of libraries enabling the user to create applications with one or more windows into which rendered radar video is displayed in PPI, A-scan or B-scan format. Additional video data, such as charts and track symbology, can be added to these windows as overlay and underlay layers. The API provides real-time control of all radar display characteristics from window sizing and zooming to programmable fade and color parameters.
Radar scan conversion in a single-slot 6U VME embedded form factor
Rugged CWCDS SVME-1905 SBC
XMC-710 graphics controller XMC card
Optional dual-channel high bandwidth radar acquisition capability
Optional SoftScan/RDS application software supports turnkey radar display console
L0, L50, L100 and L200 ruggedization levels (only L0 and L50 if radar acquisition included)
For pricing and availability information please contact the factory.
For additional information on CWCDS please visit: .
For editorial information regarding Curtiss-Wright Controls Defense Solutions products or services, contact John Wranovics, public relations director, Curtiss-Wright Controls, Tel: (925) 640-6402; email: .
Sales inquiries: Please forward all Sales and reader service inquiries to Jerri-Lynne Charbonneau, Curtiss-Wright Controls Defense Solutions, Tel: (613) 254-5112; Fax: (613) 599-7777; email: . Curtiss-Wright Controls Defense Solutions, Tel: (978) 952-2017; email:
Curtiss-Wright Controls Defense Solutions (CWCDS) is a long established technology leader in the development of rugged electronic modules and systems for defense applications. CWCDS serves as a technology and integration partner to its customers, providing a full range of advanced, highly engineered solutions from modular open systems approaches to fully custom optimized solutions. Our unmatched capabilities and product breadth span from industry standard based COTS modules to complete electronic subsystems. The company's modules and systems are currently deployed in a wide range of demanding defense & aerospace applications including C4ISR systems, unmanned subsystems, mission computing, fire control, turret stabilization, and recording & storage solutions. Additionally, the company's broad engineering capabilities combine systems, software, electrical, and mechanical design expertise with comprehensive program management and a broad range of life-cycle support services. For more information visit .
Headquartered in Charlotte, NC, Curtiss-Wright Controls is the Motion Control segment of Curtiss-Wright Corporation. With manufacturing facilities around the world, Curtiss-Wright Controls is a leading technology-based organization providing niche motion control products, subsystems and services internationally for the aerospace and defense markets. For more information, visit .
NOTE: All trademarks are property of their respective owners.
For a hi-res version of the SoftScan/1905 press release photo, .
