New piezo nanopositioning system: versatile, fast and compact with large clear aperture
Large clear aperture, high control dynamics, fast settling times and compact dimensions: PI launches a new product line of linear nanopositioning systems for a broad range of applications.
P-630: Versatile nanopositioning system with high control dynamics and fast settling times.(firmenpresse) - . The P-630 stages are perfectly suited, e.g. for use in sensor heads or precision motion of objects in optical and tactile metrology as well as for microstructuring.
With travel ranges up to 80 µm and a direct piezo actuator drive, the compact positioning stages reach high scanning frequencies and settling times of only a few milliseconds. At a width of only 50 mm, their clear aperture is relatively large with a diameter of 30 mm.
The drive technology of the highly dynamic piezo nanopositioning systems is based on all-ceramic insulated PICMA® piezo actuators. They have a proven longer lifetime and higher reliability than conventional polymer-insulated actuators.
The P-630 stages achieve nanometer-precise positioning accuracy and stability is using an integrated capacitive position sensor.
Optimum control properties are ensured via the high performance single-channel E-709.CHG Motion Controller. Its digital technology allows for refined linearization algorithms to improve accuracy; the operating parameters can easily be optimized via software.
Further Information available at:
http://www.physikinstrumente.com/en/products/prdetail.php?sortnr=202550
Themen in dieser Pressemitteilung:
Unternehmensinformation / Kurzprofil:
PI in Brief
For over 40 years, the PI Group has been one of the leading players in the global market for precision positioning technology. PI is well known for the high quality of its products and develops and manufactures standard and OEM products with piezo or motor drives. With four sites in Germany and ten sales and service offices abroad, the PI Group is represented internationally.
